Triple Offset Valve (Metal & Graphite Seat / Solid Metal Seat) For Cryogenic Service
- TOD-CX is suitable for industrial cryogenic applications.
- Robust single piece shaft with shaft bearing extension to disc.
- Absolute Zero-Leakage (0mm3/s)-196℃ using Laminated seat.
- Clean booth exclusively for assembly of cryogenic valves.
- Genuine fire safety feature with Triple Offset Design.
- Friction-less design allows a low torque operation.
- Customizing capability of pressure, size and materials.
- Extended bonnet prevents any packing deformations.
- Unicom’s stringent quality inspection and testing.
- Manufacturing expertise from casting to assembly.
- Field-proven technology and Superior customer service.
| Type | Triple Offset Butterfly Valve for Cryogenic Service |
|---|---|
| Design | ASME B16.34 / API std. 609 / BS 6364 |
| Rating | ASME Cl. 150,300,600,900 PN10, 16, 20, 25, 40, 64, 100 |
| Size | DN80(3“) to DN1200 (48”) |
| Connection Type | Double Flanged / Lugged & Wafer / Butt Weld End |
| Temperature Range | -196℃ ~250℃ |
| Main Material |
Body : CF8, CF8M, CF3, CF3M etc. Extended Bonnet : CF8, CF8M, CF3, CF3M etc. Disc : CF8, CF8M, CF3, CF3M (With Stellite or ENP) etc. Shaft : XM-19, 17-4PH, 316SS etc. Seat : 316ss + Graphite, PCTFE, PTFE etc. |
| Operator |
Manual Worm Gear Pneumatic Actuator Electric Actuator |
| Application |
Cryogenic Application Industry All liquid Gases Gasification Plants and Storage LPG/LNG Storage and Transportation Plant Engineering Petrochemical Plant Gas Industry Ship Building Chemical Plant |
| Option |
Stellite or ENP on Disc Anti-static device Manual operator with Locking device Bonnet / Stem extension Heating jacket ISO 15848 Fugitive Emission packing NACE MR 0103 / 0175 |
Designed to ensure fire safety.
